StarTech 2-Port 10G Fiber Network Card with Open SFP - PCIe, Intel Chip

SKU AB86526 Model# PEX20000SFPI
StarTech 2-Port 10G Fiber Network Card with Open SFP - PCIe, Intel Chip(PEX20000SFPI) - 1

StarTech 2-Port 10G Fiber Network Card with Open SFP - PCIe, Intel Chip

Description
SKU AB86526 Model# PEX20000SFPI
• StarTech 2-Port 10G Fiber Network Card with Open SFP PCIe, Intel Chip
• Add two 10 Gigabit Fiber Ethernet ports (10 Gbps per port) using the SFP+ transceivers of your choice to your PCIe-enabled server or workstation
View full item details
$696.58
Sale price  $696.58
Awaiting stock

In stock with supplier

Ships within 8 - 24 days

Payment plan Payment plan Payment plan
Payment plan
Payment plan Payment plan Payment plan
Payment plan
Bank Transfer

BANK TRANSFER (EFT)

Help icon

Need help? Ask our team

Email
$696.58
Sale price  $696.58
Awaiting stock

In stock with supplier

Ships within 8 - 24 days

Accepted payment methods

  • Visa
  • Mastercard
  • American Express
  • PayPal
  • UnionPay
  • Alipay
  • WeChat Pay
  • LatitudePay
Help icon

Need help? Ask our team

Email
Description
• StarTech 2-Port 10G Fiber Network Card with Open SFP PCIe, Intel Chip
• Add two 10 Gigabit Fiber Ethernet ports (10 Gbps per port) using the SFP+ transceivers of your choice to your PCIe-enabled server or workstation
View Full Details

Frequently bought with

Get fast, high-bandwidth connectivity with this cost-effective fiber network card. It adds two open SFP+ slots to your server or high-powered workstation, giving you an easy way to connect your server or workstation to a 10 Gigabit fiber network using the SFP+ modules of your choice.

Transfer files at faster speeds

Large file transfers, multimedia content and increased numbers of network users create constant pressures for more bandwidth in your network infrastructure. This fiber NIC lets you harness the speed and stability of a 10 Gigabit network. The NIC supports data transfers at up to 10Gbps per port, or up to 20Gbps per port in full-duplex mode.

Add scalable network connections to your server or workstation

The fiber NIC is compatible with most 10GbE SFP+ transceivers, giving you flexible configuration options to connect your computer directly to a fiber network at greater distances.

The card features two open SFP+ slots with support for interchangeable SFP+ modules, including the StarTech.com 10GBase-SR SFP+ Fiber Transceiver Module (SKU: SFP10GSRST). This gives you the option to use the modules that best suit your network needs based on distance and connector type. StarTech.com SFP+ Cables provide a dependable solution for linking telecom and data communications equipment, such as routers and switches.

Enhance your network capabilities

The 10 Gigabit network card features the Intel® 82599 chipset, designed to deliver the power, performance and enhanced capabilities you need for reliable network connections to your server or computer. The Intel chip offers many advanced features including Intel® Virtualization Technology for connectivity, PXE network boot support and up to 15K jumbo frame support.

The PEX20000SFPI is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Performance
Compatible Networks 10 Gbps
Full Duplex Support Yes
Jumbo Frame Support 15K max.
Maximum Data Transfer Rate 20000 Mbps (20 Gbps) - Full-Duplex
Promiscuous Mode Yes
Packaging Information
Shipping (Package) Weight 178 g [6.3 oz]
Hardware
Ports 2
Interface Fiber (10 Gigabit Ethernet)
Industry Standards IEEE 802.3ae (10GBASE-LR/SR only), IEEE 802.3aq (10GBASE-LRM)
PCI Express Rev 2.0, using PCIe x8 (or higher) slot
Chipset ID Intel - 82599
Card Type Standard Profile (LP bracket incl.)
Bus Type PCI Express
Environmental
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Operating Temperature 5°C to 50°C (41°F to 122°F)
Humidity 20% ~ 80% RH
Connector(s)
Internal Ports SFP+ Slot Female
Connector Type(s) PCI Express x8 Male
Performance
Supported Protocols IEEE 802.3ad (Link Aggregation)
IEEE 802.3x (2005 Flow Control Support)
IEEE 802.1Q (VLAN tagging)
Physical Characteristics
Color Black
Product Height 120 mm [4.7 in]
Product Length 135 mm [5.3 in]
Product Weight 102 g [3.6 oz]
Product Width 18 mm [0.7 in]
Software
OS Compatibility Windows® 7, 8, 8.1, 10
Windows Server® 2008 R2, 2012, 2012 R2, 2016
Linux 2.6.24 to 4.11.x LTS Versions only
What's in the Box
Included in Package Low-profile bracket
PCIe 10GBase Fiber Card
Quick install guide
Add two 10 Gigabit Fiber Ethernet ports (10 Gbps per port) using the SFP+ transceivers of your choice to your PCIe-enabled server or workstation
PCIe
Intel Chip
StarTech 2-Port 10G Fiber Network Card with Open SFP
