Vantrue N4S 3-Channel GPS WiFi Dash Cam

Recording Channels: 3 (Front 4K @ 30 fps / Cabin 1080p @ 30 fps / Rear 1080p @ 30 fps)

Image Sensors: Front – Sony STARVIS 2 IMX678 / Cabin – Sony STARVIS 2 IMX307 / Rear – GC4653 sensor

Field of View (FOV): Front 155° / Cabin 165° / Rear 160°

Processor: Novatek NT98529 chipset

Video Format: MP4 (H.265 / H.264 codec)

Display: 3.19 inch IPS screen for playback and menu control

Connectivity: Dual-band Wi-Fi (2.4 GHz / 5 GHz), USB-C port, built-in GPS

Audio: Integrated microphone & speaker; support for external mic (optional)

Storage: microSD card up to 512 GB (Class 10 / U3 recommended)

Power Source: Supercapacitor for heat and cold resistance (−20 °C to +70 °C operating range)

Parking Mode: Buffered motion detection and impact recording with time-lapse options (hard-wire kit required)

Voice Control Languages: English, Chinese, Japanese, Russian, French

Audio Enhancements: AEC, AGC, Noise Reduction for clear cabin recordings

Dimensions (Main Unit): ≈ 124 mm x 69 mm x 50 mm

Weight: ≈ 110 g (main unit only)

Operating Environment: −20 °C to 70 °C; Storage −30 °C to 85 °C; Humidity 10 – 90% non-condensing

What's in the Box:

Vantrue N4 S front camera unit

Rear camera with connection cable

Built-in IR cabin camera module

Car charger (USB-C)

Mount with adhesive pad and wiring clips

Quick Installation Guide / User Manual
