Ubiquiti Networks UDB Pro UniFi Device Bridge

Ubiquiti Networks UDB Pro UniFi Device Bridge

SKU AC80435 Model# UDB-PRO

(0)
Ubiquiti Networks UDB Pro UniFi Device Bridge(UDB-Pro) - 1
  • Ubiquiti Networks UDB Pro UniFi Device Bridge(UDB-Pro) - 1
  • Ubiquiti Networks UDB Pro UniFi Device Bridge(UDB-Pro) - 2
  • Ubiquiti Networks UDB Pro UniFi Device Bridge(UDB-Pro) - 3
  • Ubiquiti Networks UDB Pro UniFi Device Bridge(UDB-Pro) - 4
  • Ubiquiti Networks UDB Pro UniFi Device Bridge(UDB-Pro) - 5
Ubiquiti Networks UDB Pro UniFi Device Bridge
Ubiquiti Networks UDB Pro UniFi Device Bridge

Ubiquiti Networks UDB Pro UniFi Device Bridge

Description
SKU AC80435 Model# UDB-PRO
• Ubiquiti Networks UDB Pro UniFi Device Bridge Wi-Fi 5
• Coverage Area: 5 km (3.1 mi)
• Weatherproofing: IPX6
• Power Supply: 48V, 0.32A PoE adapter (Included)
• UDB-Pro
View full item details
Ubiquiti Networks UDB Pro UniFi Device Bridge
$366.00
$366.00
Sold out
Awaiting stock
Payment plan Payment plan Payment plan
Payment plan
Payment plan Payment plan Payment plan
Payment plan
Bank Transfer

BANK TRANSFER (EFT)
Help icon

Need help? Ask our team

Email
Promotional banner
Ubiquiti Networks UDB Pro UniFi Device Bridge
$366.00
$366.00
Awaiting stock
  • Visa
  • Mastercard
  • American Express
  • PayPal
  • UnionPay
  • Alipay
  • WeChat Pay
  • LatitudePay
Help icon

Need help? Ask our team

Email
Ubiquiti Networks UDB Pro UniFi Device Bridge
Description
• Ubiquiti Networks UDB Pro UniFi Device Bridge Wi-Fi 5
• Coverage Area: 5 km (3.1 mi)
• Weatherproofing: IPX6
• Power Supply: 48V, 0.32A PoE adapter (Included)
• UDB-Pro
View Full Details

Frequently bought with

Dimensions
Ø189.5 x 64.3 mm (Ø7.4 x 2.5")
WiFi Standard
WiFi 5
Spatial Streams
2
Coverage Area
5 km (3.1 mi)
Mounting Locations
Wall, pole
Mounting
Pole (Included)
Weatherproofing
IPX6
Power Method
PoE PoE+ (Required for PoE output)
Power Supply
48V, 0.32A PoE adapter (Included)
MIMO
5 GHz
2 x 2
Max. Data Rate
5 GHz
867 Mbps (BW80)
Antenna Gain
5 GHz
19 dBi
Max. TX Power
5 GHz
25 dBm
Max. Conducted TX Power
25 dBm (Combined)
Supported Data Rates
802.11ac (WiFi 5)
6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps
Wireless Security
WPA2 AES
Max. Power Consumption
9W
Supported Voltage Range
42.5—57V DC
Networking Interface
(2) GbE RJ45 ports
Antennas
Internal
Management
(1) PoE in (PoE output not used) (1) Passive PoE output
Channel Bandwidth
20/40/80 (MHz)
Wind Loading
69 N at 200 km/h (15.5 lbf at 125 mph)
Weight
Device: 431 g (0.95 lb) With mount: 515 g (1.1 lb)
Enclosure Material
UV-resistant polycarbonate
Mount Material
UV-stabilized polycarbonate, stainless steel
Pole Mount Diameter
0.8–2.1" (20–53.1 mm)
Button
(1) Factory-reset
LEDs
System
Power, (2) Ethernet status - main port/PoE out port, (4) signal strength
NDAA Compliant
?
Certifications
CE, FCC, IC
Operating Frequency
US/CA: U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz Worldwide: 5150 - 5875 MHz
Ambient Operating Temperature
-40 to 60° C (-40 to 140° F)
Ambient Operating Humidity
5 to 95% noncondensing
Ubiquiti Networks UDB Pro UniFi Device Bridge
Coverage Area: 5 km (3.1 mi)
Power Supply: 48V
0.32A PoE adapter (Included)
Ubiquiti Networks UDB Pro UniFi Device Bridge
UDB-Pro
Weatherproofing: IPX6
Wi-Fi 5
