TP-Link DS105GP Omada 5-Port Gigabit Desktop Switch with 4-Port PoE+
TP-Link DS105GP Omada 5-Port Gigabit Desktop Switch with 4-Port PoE+
Description
• Fan: Fanless
• PoE Ports (RJ45): 802.3 af/at compliant (Standard), Ports 14, 65W Power Supply
• Switching Capacity: 10Gbps
• Packet Forwarding Rate: 7.44Mpps
• MAC Address Table: 2K
• Jumbo Frame: 16KB
• DS105GP
In stock with supplier
BANK TRANSFER (EFT)
In stock with supplier
Accepted payment methods
Description
• Fan: Fanless
• PoE Ports (RJ45): 802.3 af/at compliant (Standard), Ports 14, 65W Power Supply
• Switching Capacity: 10Gbps
• Packet Forwarding Rate: 7.44Mpps
• MAC Address Table: 2K
• Jumbo Frame: 16KB
• DS105GP
Features
- 5x 10/100/1000 Mbps RJ45 ports
- With four PoE+ ports, transfers data and power on one single cable
- Works with IEEE 802.3af/at compliant PDs
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Supports PoE Power up to 30 W for each PoE port
- Supports PoE Power up to 65 W for all PoE ports*
- Up to 250m (820ft) data and power transmitting range under Extend Mode**
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Plug and Play. No configuration or central management required.
*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.
**The speed of the ports which are under extend mode will be downgraded to 10Mbps. Actual transmission distance may vary from the quality of the cables.
- Omada Unmanaged Switches do not support Omada SDN central management.
Fan: Fanless
Interface: 5x 10/100/1000Mbps RJ45 Ports
AUTO Negotiation
AUTO MDI/MDIX
Jumbo Frame: 16KB
MAC Address Table: 2K
Packet Forwarding Rate: 7.44Mpps
PoE Ports (RJ45): 802.3 af/at compliant (Standard)
Ports 14
65W Power Supply
Switching Capacity: 10Gbps
