This USB-C™ multiport video adapter offers a portable solution for connecting your USB Type-C laptop to a VGA, DVI, HDMI® or Mini DisplayPort (mDP) display.

All-in-One Video Connectivity with Travel in Mind

Avoid the hassle of carrying different adapters, with a 4-in-1 USB-C monitor adapter. With VGA, DVI, HDMI and mDP output, you can connect your laptop to any display using this multiport adapter. The adapter features a magnetic retainer that guides the breakout cable into place for quick, secure portability. With a durable aluminum enclosure, the adapter can withstand being carried in your travel bag.

Ultra HD 4K 60Hz Resolution

The HDMI and mDP outputs on this USB-C video adapter support UHD resolutions up to 4K 60Hz, while the VGA and DVI outputs support HD resolutions up to 1920x1200. Stylish Connectivity for Your MacBook, MacBook Pro, or Any Laptop The USB-C adapter has a Space Gray housing and built-in USB-C cable designed to match your Space Gray MacBook, or MacBook Pro.

The adapter is compatible with USB-C DP Alt Mode devices.

The adapter is also available with 4K 30Hz HDMI resolution support, in three colors: Space Gray (CDPVDHDMDPSG), Rose Gold (CDPVDHDMDPRG) and Silver (CDPVGDVHDMDP), so you can choose an adapter that matches your laptop or your color preference.

CDPVDHDMDP2G is backed by a StarTech.com 3-year warranty and free lifetime technical support.

Connector(s)
Connector A	USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B	DVI-I (29 pin) Female Output
	HDMI (19 pin) Female Output
	Mini-DisplayPort (20 pin) Female Output
	VGA (15 pin, High Density D-Sub) Female Output
Environmental
Humidity	Storage: 5% ~ 90 % RH (no condensation) Operating: 10% ~ 85 % RH (no condensation)
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-10°C to 70°C (14°F to 158°F)
Hardware
Active or Passive Adapter	Active
AV Input	USB Type-C
AV Output	DVI
	HDMI
	Mini-DisplayPort
	VGA
Chipset ID	Cypress - CYPD3120 Parade - PS8348 Parade - PS8617 Parade - PS8338 Parade - PS171 Parade - PS176
Packaging Information
Shipping (Package) Weight	0.1 kg [0.3 lb]
Performance
Audio Specifications	HDMI or mDP output: 7.1 surround sound
Maximum Analog Resolutions	1920 x 1200 @ 60Hz
Maximum Digital Resolutions	4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz (HDMI) 4096 X 2160 @ 60Hz (mDP)
Supported Resolutions	Maximum HDMI output: 4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz Maximum mDP output: 4096 X 2160 @ 60Hz Maximum DVI and VGA output: 1920 x 1200 @ 60Hz Lower resolutions and refresh rates may also be supported
Video Revision	DisplayPort 1.2
	HDMI 2.0
Wide Screen Supported	Yes
Physical Characteristics
Cable Length	115 mm [4.5 in]
Color	Space Gray
Enclosure Type	Aluminum
Product Height	30 mm [1.2 in]
Product Length	175 mm [6.9 in]
Product Weight	185 g [6.5 oz]
Product Width	142 mm [5.6 in]
Prominence
Description CDW 75 - 1st Line	StarTech.com USB-C Multiport Video Adapter - 4-in-1 A/V Adapter - 4K 60Hz
Special Notes / Requirements
Note	Only one video output is supported on the video adapter at a time, if multiple connections are made, only one of the outputs will function
What's in the Box
Included in Package	travel A/V adapter

4-in-1 multiport USB-C video adapter to any one of HDMI 2.0 or Mini DisplayPort 1.2 (4K 60Hz) | VGA or DVI (1080p) | HDCP 2.2/1.4 |Thunderbolt 3 compatible
For USB Type C laptops like Dell XPS Precision Latitude/Lenovo ThinkPad X1 Carbon Extreme/Surface Laptop 3 Book 3/MacBook Pro Air/HP EliteBook Spectre ZBook/Chromebooks
No Drivers Windows macOS Linux Chrome OS
Portable & durable aluminum Space Gray housing w/ magnetic hideaway cable
Tested w/ range of displays/monitors/projectors
