StarTech USB 3.0 Dual SSD / HDD Dock w/ UASP for 2.5 3.5in SATA 6 Gbps

SKU AB86717 Model# SDOCK2U33
StarTech USB 3.0 Dual SSD / HDD Dock w/ UASP for 2.5 3.5in SATA 6 Gbps(SDOCK2U33) - 1

StarTech USB 3.0 Dual SSD / HDD Dock w/ UASP for 2.5 3.5in SATA 6 Gbps

Description
SKU AB86717 Model# SDOCK2U33
• StarTech USB 3.0 Dual SSD / HDD Dock w/ UASP for 2.5 3.5in SATA 6 Gbps Dock two 2.5" or 3.5" SATA III SSDs/HDDs over USB 3.0 with UASP
View full item details
$133.95
Sale price  $133.95
Awaiting stock

In stock with supplier

Ships within 8 - 24 days

Payment plan Payment plan Payment plan
Payment plan
Payment plan Payment plan Payment plan
Payment plan
Bank Transfer

BANK TRANSFER (EFT)

Help icon

Need help? Ask our team

Email
$133.95
Sale price  $133.95
Awaiting stock

In stock with supplier

Ships within 8 - 24 days

Accepted payment methods

  • Visa
  • Mastercard
  • American Express
  • PayPal
  • UnionPay
  • Alipay
  • WeChat Pay
  • LatitudePay
Help icon

Need help? Ask our team

Email
Description
• StarTech USB 3.0 Dual SSD / HDD Dock w/ UASP for 2.5 3.5in SATA 6 Gbps Dock two 2.5" or 3.5" SATA III SSDs/HDDs over USB 3.0 with UASP
View Full Details

Frequently bought with

The SDOCK2U33 Dual 2.5/3.5" SATA hard drive docking station lets you dock and swap drives from your desktop or laptop computer simultaneously, using a single USB port.

Enhanced with UASP (USB Attached SCSI Protocol), this hard drive docking station lets you get the most out of the fastest drive technologies such as SATA III (6 Gbps), solid state drives (SSD) and hybrid, drives with performance up to 70% faster than conventional USB 3.0 when paired with a UASP-enabled host controller. See our UASP testing results below for further details.

The hard drive dock features independent power buttons for each individual drive, ensuring you can operate each hard drive separately. This gives you the freedom to hot-swap one drive while transferring data to another, saving you time.

Extend the value of this hard drive docking station further with the addition of our SATA to IDE Hard Drive Adapter (SAT2IDEADP), allowing easy insertion of any 2.5 or 3.5in. IDE hard drive into a SATA hard drive dock.

To ensure compatibility with your computer system, the SDOCK2U33 supports all of the leading operating systems, including: Microsoft Windows® (8/7/Vista/XP/Server 2008/Server 2003), Apple® OSX (10.9/10.8/10.7/10.6), Linux, and Google Chrome OS™.

SDOCK2U33 is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Improved Performance with UASP

UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing, UASP performs with a 70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.

UASP Speed Diagram

At the same peak in testing UASP also shows an 80% reduction in required processor resources.

UASP Speed Diagram

Testing results were obtained using an Intel® Ivy Bridge system, a UASP-enabled StarTech.com Enclosure, and a SATA III solid state drive.

Connector(s)
Drive Connectors SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors USB Type-B (9 pin) USB 3.0 Female
Environmental
Humidity 20%RH~80%RH
Operating Temperature 5°C to 35°C (41°F to 95°F)
Storage Temperature -20°C to 50°C (-4°F to 122°F)
Hardware
Chipset ID VIA/VLI - VL812
ASMedia - ASM1053 - 6G
Compatible Drive Types SATA
Drive Installation Removable
Drive Size 2.5in & 3.5in
Fan(s) No
Interface USB 3.0
Number of Drives 2
Indicators
LED Indicators Drive Power / Activity
Packaging Information
Shipping (Package) Weight 950 g [33.5 oz]
Performance
Insertion Rating 15,000 Cycles
Max Drive Capacity Currently tested with up to 4TB 7200 RPM 3.5" hard drives per bay (8TB total) and 2TB 5900 RPM 2.5" hard drives (2TB total)
MTBF 30,000
Type and Rate USB 3.0 - 5 Gbit/s
UASP Support Yes
Physical Characteristics
Color Black
Enclosure Type Plastic
Product Height 70 mm [2.8 in]
Product Length 148 mm [5.8 in]
Product Weight 498 g [17.6 oz]
Product Width 132 mm [5.2 in]
Power
Input Current 1.3 A
Input Voltage 100 ~ 240 AC
Output Current 3 A
Output Voltage 12 DC
Plug Type M
Power Consumption (In Watts) 36
Power Source AC Adapter Included
Software
OS Compatibility OS independent; No software or drivers required
What's in the Box
Included in Package 3ft (1m) USB 3.0 Cable
Instruction Manual
Universal power adapter: comes ready for NA/EU/UK only when you buy in NA/EU/UK; comes ready for Australia and New Zealand only when you buy in Australia and New Zealand
USB 3.0 to Dual 2.5/3.5in SATA hard drive docking station
Dock two 2.5" or 3.5" SATA III SSDs/HDDs over USB 3.0 with UASP
StarTech USB 3.0 Dual SSD / HDD Dock w/ UASP for 2.5 3.5in SATA 6 Gbps
