This Thunderbolt 3 USB 3.1 multi-channel hub controller delivers maximum USB performance, adding four high-speed independent USB ports to your Thunderbolt 3 laptop. It provides three dedicated USB controllers and up to 20Gbps of aggregated bandwidth for USB devices, ideal for connecting bandwidth-demanding devices such as 3D scanners.

The Thunderbolt 3 hub lets you access multiple USB devices at greater bandwidth and improved performance, and extend the life of your USB devices.

Maximize USB Performance

The high-speed USB hub provides two 10Gbps ports for connecting high-performance devices such as storage arrays, 3D scanners, audio-video devices, and external SSDs, with dedicated bandwidth for faster read/write access. The second Thunderbolt 3 port can be used to connect an additional USB-C device with up to 10G bandwidth.

Dedicated Independent Port Bandwidth

When only one USB port is in use, the full 10Gbps bandwidth is available to the device. Two additional USB-A ports provide 5Gbps of bandwidth to each device simultaneously, ideal for portable hard drives or flash drives. For added convenience, the front USB-A port supports both data and charging of your mobile device.

Extend Your Workstation

The Thunderbolt 3 hub features a second Thunderbolt 3 port to connect an additional display to your laptop (a USB-C video adapter may be required). The port can also be used to connect additional Thunderbolt devices, daisy-chaining up to six devices.

The TB33A1C is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Connector(s)
Connector Type(s)	Thunderbolt™ 3 USB-C (24-pin) (40Gbps) Female
	USB 3.1 USB Type-A (9 pin, Gen 2, 10 Gbps) Female
	USB Type-A (9 pin) USB 3.0 Female
	USB Type-C (24 pin) USB 3.1 (10Gbps) Female
Environmental
Humidity	90% RH
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Hardware
Bus Type	Thunderbolt 3
	USB 3.1 Gen 1
	USB 3.1 Gen 2
Chipset ID	Intel - Alpine Ridge JHL6540 ASMedia - ASM1042A ASMedia - ASM1142
Fast-Charge Port(s)	No
Industry Standards	Thunderbolt 3 USB Battery Charging Specification Rev. 1.2 Universal Serial Bus 3.1 Specifications Revision 1.0 Universal Serial Bus Specification Revision 2.0 Extensible Host Controller Interface Specification revision 1.1 USB Attached SCSI Protocol Revision 1.0
Ports	4
USB-C Device Port(s)	Yes
USB-C Host Connection	No
Packaging Information
Package Height	11.6 cm [4.6 in]
Package Length	28.5 cm [11.2 in]
Package Width	18.5 cm [7.3 in]
Shipping (Package) Weight	1.6 kg [3.4 lb]
Performance
Maximum Data Transfer Rate	Aggregate Bandwidth 20Gbit/s
MTBF	1,936,146 hours
Type and Rate	USB 3.1 Gen 1 - 5 Gbit/s
	USB 3.1 Gen 2 - 10 Gbit/s
UASP Support	Yes
Physical Characteristics
Cable Length	50 cm [19.7 in]
Color	Silver & Black
Enclosure Type	Aluminum
Form Factor	Desktop
Product Height	2.4 cm [0.9 in]
Product Length	14.8 cm [5.8 in]
Product Width	74 mm [2.9 in]
Weight of Product	200 g [7.1 oz]
Power
Center Tip Polarity	Positive
Input Current	1.8 A
Input Voltage	100 - 240 AC
Output Current	3.25 A
Output Voltage	20V DC
Plug Type	N
Power Consumption (In Watts)	65W
Power Delivery	15W
Power Source	AC Adapter Included
Prominence
Description CDW 75 - 1st Line	StarTech.com Thunderbolt 3 USB 3.1 Multi-Channel Hub Controller - 10G /5G
Software
OS Compatibility	Windows® 7, 8, 8.1, 10 macOS 10.12 - 10.3
Special Notes / Requirements
Note	Secondary Thunderbolt 3 port can also be used to connect USB 3.1 (10Gbps) USB-Type C devices, such as USB 3.1 Storage Enclosure or Hubs. Backwards compatible with USB 3.1 Gen 1 (USB 3.0), and USB 2.0.
	USB 3.1 Gen 1 is also known as USB 3.0; this connectivity standard offers speeds up to 5Gbps. USB 3.1 Gen 2 offers speeds up to 10Gbps.
	When connecting a display to the Thunderbolt 3 USB-C port, a USB-C video adapter might be required depending on the input of your display.
System and Cable Requirements	Thunderbolt 3 equipped computer with a Thunderbolt 3 port.
	Your laptop's Thunderbolt 3 port must support USB Power Delivery 2.0 in order to power and charge your laptop.
What's in the Box
Included in Package	quick-start guide
	Thunderbolt 3 Cable (50 cm)
	Thunderbolt 3 controller
	universal power adapter (NA/JP, UK, EU, ANZ)

3 dedicated controllers over 4x PCIe lanes for high-performance USB transfer speeds | One controller for each 5Gbps port | 10Gbps ports share controller
Flexible TB3 port: DP Alt Mode for 2nd monitor 4K 60Hz/TB3 daisy chain/USB Type-C port
For SSDs/NVMe/VR headsets/3D scanners
Hub auto installs on Win/MacOS | 1.6" TB3 cable | 65W PSU
Thunderbolt 3 to USB Controller w/ 2x USB-A 5Gbps USB 3.0 (USB 3.1/3.2 Gen 1) | 1x USB-A/1x USB-C at 10Gbps (Gen 2) | BC 1.2 Fast Charge port 7.5W
