The HDMI® over IP receiver works with the HDMI over IP Extender (ST12MHDLNHK) to distribute HDMI to an additional remote display. You can add multiple receivers (each sold separately) to easily distribute HDMI to multiple locations. Customize your video distribution with a scalable solution With additional receivers, you can scale your HDMI over IP kit installation to suit your needs. In a point-to-multipoint setup, you can route HDMI over IP to as many receivers as you need. For additional scalability, you can combine up to 99 different kits (ST12MHDLNHK) to create a multipoint-to-multipoint setup, where you can route different HDMI source signals to different displays. Mounting hardware and IR extenders are included for each transmitter and receiver to ensure tidy, professional installation and hassle-free remote operation.

Get brilliant video at HD 1080p

The receiver maintains your HD video signal, supporting resolutions up to 1080p. Maintaining your HD quality over IP makes it easy to distribute dynamic digital signage throughout your site to attract and engage customers.

Save your network bandwidth with video compression

Unlike some video-over-IP solutions that consume your bandwidth, this HDMI over IP solution uses video compression to distribute high-quality HDMI over your local area network, with minimal bandwidth requirements. Extending your HDMI using compression saves your network resources, avoiding the hassle of a separate video network.

The ST12MHDLNHR is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Connector(s)
Remote Unit Connectors	2.5 mm Mini-Jack (3 Position) Female
	HDMI (19 pin) Female Output
	Infrared Female
	RJ-45 Female Input
Environmental
Humidity	0% - 80 %
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-10°C to 60°C (14°F to 140°F)
Hardware
Audio	Yes
Cabling	Cat 5e UTP or better
Daisy-Chain	Yes
Ports	1
Rack-Mountable	Yes
Indicators
LED Indicators	status LED
Packaging Information
Package Height	63 mm [2.5 in]
Package Length	16.8 cm [6.6 in]
Package Width	14.3 cm [5.6 in]
Shipping (Package) Weight	0.1 kg [0.1 lb]
Performance
Audio Specifications	2-channel
Max Distance	15 m / 50 ft
Maximum Cable Length	15.2 m [50 ft]
Maximum Digital Resolutions	1920x1200 (1080p) 60Hz
Supported Resolutions	1920x1200 60Hz
Wide Screen Supported	Yes
Physical Characteristics
Color	Black
Enclosure Type	Aluminum
Product Height	2.8 cm [1.1 in]
Product Length	13 cm [5.1 in]
Product Width	97 mm [3.8 in]
Weight of Product	448 g [15.8 oz]
Power
Input Current	0.3 A
Input Voltage	100 - 240 AC
Output Current	1 A
Output Voltage	5 DC
Plug Type	USB Mini-B (5 pin)
Power Source	AC Adapter Included
Special Notes / Requirements
Note	Each kit requires 6 to 12mbps of local area network bandwidth, when in operation
	Your router must support IGMP snooping. Please refer to your network switch or router documentation to ensure IGMP snooping is supported and enabled
What's in the Box
Included in Package	CAT5 cables
	DB9 to 2.5 mm serial adapter cable
	HDMI over IP receiver
	instruction manual
	IR receiver
	IR remote control
	mounting bracket
	plastic screwdriver
	rubber feet
	universal power adapter (NA, EU, UK, ANZ)
	USB-A to Mini USB-B cable

Broadcast your HDMI signal to multiple locations throughout your site using your existing network infrastructure
Create a digital signage solution with a scalable HDMI over CAT6 receiver
Maintain the HD picture quality of your video source with a 1080p HDMI receiver
Use this HDMI over Ethernet Receiver to distribute video over your site using your network
Video over IP / HDMI over LAN / HDMI over network / HDMI video over Ethernet / HDMI over Gigabit Ethernet / HDMI over CAT5 receiver
