StarTech 4-Port Serial PCIe Adapter Card - PCIe Serial DB9
StarTech 4-Port Serial PCIe Adapter Card - PCIe Serial DB9
Description
• 4-Port Serial PCIe Card, Quad-Port PCI Express to RS232/RS422/RS485 (DB9) Serial Card Colour: Black
• Low-Profile Bracket Incl.
• 16C1050 UART
• Windows/Linux
• TAA Compliant
• Level-4 ESD Protection
• Connector Type: 1
• PCI Express x1
• External Ports: 4
• 9 pin D-Sub (DB-9) Male
• MTBF: 6,548,788 Hours
• Bus Type: PCI Express
• Card Type: Standard Profile
• FIFO: 256 Bytes
• PS74ADF-SERIAL-CARD
• Low-Profile Bracket Incl.
• 16C1050 UART
• Windows/Linux
• TAA Compliant
• Level-4 ESD Protection
• Connector Type: 1
• PCI Express x1
• External Ports: 4
• 9 pin D-Sub (DB-9) Male
• MTBF: 6,548,788 Hours
• Bus Type: PCI Express
• Card Type: Standard Profile
• FIFO: 256 Bytes
• PS74ADF-SERIAL-CARD
$328.95
Sale price
$328.95
BANK TRANSFER (EFT)
$328.95
Sale price
$328.95
Accepted payment methods
Description
• 4-Port Serial PCIe Card, Quad-Port PCI Express to RS232/RS422/RS485 (DB9) Serial Card Colour: Black
• Low-Profile Bracket Incl.
• 16C1050 UART
• Windows/Linux
• TAA Compliant
• Level-4 ESD Protection
• Connector Type: 1
• PCI Express x1
• External Ports: 4
• 9 pin D-Sub (DB-9) Male
• MTBF: 6,548,788 Hours
• Bus Type: PCI Express
• Card Type: Standard Profile
• FIFO: 256 Bytes
• PS74ADF-SERIAL-CARD
View Full Details
• Low-Profile Bracket Incl.
• 16C1050 UART
• Windows/Linux
• TAA Compliant
• Level-4 ESD Protection
• Connector Type: 1
• PCI Express x1
• External Ports: 4
• 9 pin D-Sub (DB-9) Male
• MTBF: 6,548,788 Hours
• Bus Type: PCI Express
• Card Type: Standard Profile
• FIFO: 256 Bytes
• PS74ADF-SERIAL-CARD
Per-Port Serial Configuration
This PCIe Serial Card is equipped with on-board DIP switches, enabling each DB9 serial port to operate in RS-232, RS-422, and/or RS-485 mode(s). The card features LED indicators per port, providing real-time monitoring of port activity.
Configurable External SATA Power
The PCI Express Serial Adapter Card features three power modes that are configurable via on-board jumpers, including 12V (1.5A per port), 5V (1.5A per port), or no power (RI), over pin 9.
Legacy Connectivity
This serial card enables the continued use of legacy serial devices, preventing down time and avoiding costly upgrades. The 4-Port PCIe Serial Card is an ideal system upgrade for a wide range of applications (e.g., point-of-sale terminals, PLCs, factory control and automation, scientific sensors, medical equipment, scanners, and oscilloscopes)
Applications
- Manufacturing (CNC machinery, process control equipment, bar code scanners, and serial printers)
- POS (credit/debit card readers, receipt printers, bar code scanners, cash registers, and scales)
- Security (UPS control, access key panels, video cameras, card readers, and modems)
- Healthcare (patient monitoring equipment, nurse stations, and modems)
