StarTech 4 Bay SATA 2.5 / 3.5in SSD / HDD Dock - USB 3.1 USB-C / USB-A
StarTech 4 Bay SATA 2.5 / 3.5in SSD / HDD Dock - USB 3.1 USB-C / USB-A
Description
• USB 3.1 (10Gbps)
• USB-C and USB-A interface and backward compatible with USB 3.0, 2.0 and 1.x
• Supports SATA I/II/III (up to 6 Gbps)
• Top-loading design with independent drive doors and drive controllers and ejection buttons
• SMART support
• Built-in dual 40 mm cooling fans
• Hard Drive Docking Station / SATA SSD & HDD docking station
In stock with supplier
Ships within 8 - 24 days
BANK TRANSFER (EFT)
In stock with supplier
Ships within 8 - 24 days
Accepted payment methods
Description
• USB 3.1 (10Gbps)
• USB-C and USB-A interface and backward compatible with USB 3.0, 2.0 and 1.x
• Supports SATA I/II/III (up to 6 Gbps)
• Top-loading design with independent drive doors and drive controllers and ejection buttons
• SMART support
• Built-in dual 40 mm cooling fans
• Hard Drive Docking Station / SATA SSD & HDD docking station
This 4-bay SATA HDD docking station lets you access up to four solid-state drives or hard drives simultaneously over USB 3.1 (10Gbps), and hot swap drives with ease. Ideal for IT professionals, the docking station provides large data capacity and fast file transfers, helping you manage your workflow more efficiently. Save time accessing and managing your data When you’re managing a large number of drives, the HDD/SSD docking station saves you time. Quickly dock and swap your drives for disk imaging, data recovery from failing drives, data backups, or other tasks. The hard drive docking station also has SMART support, for accessing important drive information such as hours in use, number of power cycles, and disk health. Fast data transfers With USB 3.1 Gen 2, the HDD docking station lets you leverage the high performance of the latest SSDs and hard drives, while alleviating bottlenecks in your data transfers.
Convenient compatibility
The hard drive docking station includes a USB Type-C cable, for connecting to USB-C equipped laptops and devices, and a USB Type-A cable, for backward compatibility with your existing USB 3.0, 2.0 and 1.x devices.
The docking station also works with 2.5” and 3.5” IDE hard drives, mSATA drives and M.2 drives using a compatible StarTech.com adapter:
- IDE hard drives: Use StarTech.com adapter SAT2IDEADP SATA to 2.5in or 3.5in IDE Hard Drive Adapter
- HDD Docks mSATA drives: Use StarTech.com adapter SAT32MSAT257 mSATA SSD to 2.5in SATA Adapter
- Converter M.2 drives: Use StarTech.com adapter SAT32M225 M.2 NGFF SSD to 2.5in SATA Adapter Converter
The SDOCK4U313 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
| Connector(s) | |
| Drive Connectors | 22 pin SATA Data & Power Combo Receptacle |
| Host Connectors | USB Type-C (24 pin) USB 3.1 (10Gbps) Female |
| Environmental | |
| Humidity | 20% ~ 80% RH |
| Operating Temperature | 5°C to 35°C (41°F to 95°F) |
| Storage Temperature | -20°C to 50°C (-4°F to 122°F) |
| Hardware | |
| Bus Type | USB 3.1 Gen 2 |
| Chipset ID | VIA Labs - VL820 VIA Labs - VL715 |
| Compatible Drive Types | SATA |
| Drive Installation | Removable |
| Drive Size | 2.5in & 3.5in |
| Fan Bearing Type | Sleeve Bearing |
| Fan(s) | Yes |
| Fans | 60 mm |
| Interface | USB 3.1 Gen 2 |
| Number of Drives | 4 |
| Indicators | |
| LED Indicators | Activity |
| Power | |
| Packaging Information | |
| Package Height | 27 cm [10.6 in] |
| Package Length | 38.3 cm [15.1 in] |
| Package Width | 19.5 cm [7.7 in] |
| Shipping (Package) Weight | 2.4 kg [5.3 lb] |
| Performance | |
| 4Kn Support | Yes |
| Hot Swap Capability | Yes |
| Insertion Rating | 10000 |
| Max Drive Capacity | Tested up to 10TB |
| Maximum Data Transfer Rate | 10Gbps |
| MTBF | 30000 hours |
| Noise Level | 19.04 dBA |
| S.M.A.R.T. Support | Yes |
| TRIM Support | Yes |
| Type and Rate | SATA III (6 Gbps) |
| USB 3.1 Gen 2 - 10 Gbit/s | |
| UASP Support | Yes |
| Physical Characteristics | |
| Color | Black |
| Enclosure Type | Plastic |
| Product Height | 8.7 cm [3.4 in] |
| Product Length | 29.1 cm [11.5 in] |
| Product Width | 17.1 cm [6.7 in] |
| Weight of Product | 1 kg [2.2 lb] |
| Power | |
| Input Current | 2.0A |
| Input Voltage | 100 - 240 AC |
| Output Current | 6500mA |
| Output Voltage | 12 DC |
| Plug Type | 4-pin DIN |
| Power Consumption (In Watts) | 78 |
| Power Source | AC Adapter Included |
| Software | |
| OS Compatibility | OS independent; No software or drivers required |
| What's in the Box | |
| Included in Package | 3.3 ft [1 m] USB 3.1 (Type-A) cable |
| 3.3 ft [1 m] USB 3.1 (Type-C) cable | |
| docking station | |
| quick-start guide | |
| universal power adapter (NA/JP, UK, EU, ANZ) | |
