StarTech 1.8m Mini DisplayPort to DVI Adapter Cable - Mini DP to DVI-D
StarTech 1.8m Mini DisplayPort to DVI Adapter Cable - Mini DP to DVI-D
Description
• 1.8m Mini DisplayPort to DVI-D (digital) single-link adapter cable connects a DVI display/projector/monitor | 1080p 60Hz or 4K 30Hz (monitors w/HDMI clock-rate) | EDID Passive mDP to DVI converter cable supports Mini DisplayPort 1.2 equipped PC or Mac incl Thunderbolt 1/2 MacBook Pro/Air/Mac Mini | Workstations | Desktop Computers (AMD/Nvidia video cards) | Laptops | Docks -Integrated video adapter prevents signal loss
• Mini DP to DVI cable supports DVI screw locking cord
• OS independent
• Mini DP to DVI cable supports DVI screw locking cord
• OS independent
$31.95
Sale price
$31.95
In stock with supplier
Ships within 8 - 24 days
BANK TRANSFER (EFT)
$31.95
Sale price
$31.95
In stock with supplier
Ships within 8 - 24 days
Accepted payment methods
Description
• 1.8m Mini DisplayPort to DVI-D (digital) single-link adapter cable connects a DVI display/projector/monitor | 1080p 60Hz or 4K 30Hz (monitors w/HDMI clock-rate) | EDID Passive mDP to DVI converter cable supports Mini DisplayPort 1.2 equipped PC or Mac incl Thunderbolt 1/2 MacBook Pro/Air/Mac Mini | Workstations | Desktop Computers (AMD/Nvidia video cards) | Laptops | Docks -Integrated video adapter prevents signal loss
• Mini DP to DVI cable supports DVI screw locking cord
• OS independent
View Full Details
• Mini DP to DVI cable supports DVI screw locking cord
• OS independent
The MDP2DVIMM6B Mini DisplayPort to DVI Adapter Cable lets you directly connect your Mini DP video source (Desktop PC, Laptop, Ultrabook™, etc.) to a DVI monitor or projector, eliminating the expense of having to upgrade to a Mini DisplayPort-capable monitor.
The adapter cable is 6 feet (1.8 m) in length, and features male-to-male connectors, allowing you to connect your Mini DisplayPort source directly to a DVI display with no additional cabling required.
Compatible with Intel® Thunderbolt™, when connected directly to a supporting DisplayPort over Thunderbolt I/O port, the adapter supports resolutions up to 1920x1200 (WUXGA).
MDP2DVIMM6B is a passive adapter that requires a dual-mode DisplayPort port (DisplayPort++), meaning that DVI and HDMI signals can also be passed through the port.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
| Connector(s) | |
| Connector A | Mini-DisplayPort (20 pin) Male |
| Connector B | DVI-D (25 pin) Male |
| Environmental | |
| Humidity | 40%-85%RH |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -10°C to 70°C (14°F to 158°F) |
| Hardware | |
| Active or Passive Adapter | Passive |
| Adapter Style | Cable Adapters |
| Audio | No |
| AV Input | DisplayPort |
| AV Output | DVI |
| Chipset ID | NXP - 3361 |
| Packaging Information | |
| Shipping (Package) Weight | 0.1 kg [0.3 lb] |
| Performance | |
| Maximum Cable Length | 1.8 m [6 ft] |
| Maximum Digital Resolutions | 1920x1200 / 1080p |
| Wide Screen Supported | Yes |
| Physical Characteristics | |
| Cable Length | 1.8 m [6 ft] |
| Color | Black |
| Product Height | 15 mm [0.6 in] |
| Product Length | 1830 mm [72 in] |
| Product Weight | 110 g [3.9 oz] |
| Product Width | 40 mm [1.6 in] |
| Special Notes / Requirements | |
| System and Cable Requirements | DP++ (DisplayPort++) port required from video card or video source for DVI and HDMI® signal pass-through |
| What's in the Box | |
| Included in Package | Mini DisplayPort® to DVI Adapter |
1.8m Mini DisplayPort to DVI-D (digital) single-link adapter cable connects a DVI display/projector/monitor | 1080p 60Hz or 4K 30Hz (monitors w/HDMI clock-rate) | EDID
Mini DP to DVI cable supports DVI screw locking cord
OS independent
Passive mDP to DVI converter cable supports Mini DisplayPort 1.2 equipped PC or Mac incl Thunderbolt 1/2 MacBook Pro/Air/Mac Mini | Workstations | Desktop Computers (AMD/Nvidia video cards) | Laptops | Docks -Integrated video adapter prevents signal loss
Mini DP to DVI cable supports DVI screw locking cord
OS independent
Passive mDP to DVI converter cable supports Mini DisplayPort 1.2 equipped PC or Mac incl Thunderbolt 1/2 MacBook Pro/Air/Mac Mini | Workstations | Desktop Computers (AMD/Nvidia video cards) | Laptops | Docks -Integrated video adapter prevents signal loss
