Seasonic SS-500L1U 500W 80+ Gold APFC 1U Modular Power Supply
Seasonic SS-500L1U 500W 80+ Gold APFC 1U Modular Power Supply
Description
• Seasonic SS-500L1U 500W 80+ Gold APFC 1U Modular Power Supply 40mm Double Ball Bearing Fan
• EPS12V
• 80+ Gold Certified
• DC to DC converter design
• Seasonic S3FC
• Active PFC
• Over-voltage, Over-power, Short circuit protection
• Fully modular cables
• 1U Rackmountable
• MTBF: > 100,000 Hours
• 12 Months Limited Warranty
• EPS12V
• 80+ Gold Certified
• DC to DC converter design
• Seasonic S3FC
• Active PFC
• Over-voltage, Over-power, Short circuit protection
• Fully modular cables
• 1U Rackmountable
• MTBF: > 100,000 Hours
• 12 Months Limited Warranty
$273.95
Sale price
$273.95
In stock with supplier
Ships within 12 - 28 days
BANK TRANSFER (EFT)
$273.95
Sale price
$273.95
In stock with supplier
Ships within 12 - 28 days
Accepted payment methods
Description
• Seasonic SS-500L1U 500W 80+ Gold APFC 1U Modular Power Supply 40mm Double Ball Bearing Fan
• EPS12V
• 80+ Gold Certified
• DC to DC converter design
• Seasonic S3FC
• Active PFC
• Over-voltage, Over-power, Short circuit protection
• Fully modular cables
• 1U Rackmountable
• MTBF: > 100,000 Hours
• 12 Months Limited Warranty
View Full Details
• EPS12V
• 80+ Gold Certified
• DC to DC converter design
• Seasonic S3FC
• Active PFC
• Over-voltage, Over-power, Short circuit protection
• Fully modular cables
• 1U Rackmountable
• MTBF: > 100,000 Hours
• 12 Months Limited Warranty
- Intel EPS 12 V compliant
- 80 PLUS® Gold certification (up to 90 % efficiency at 115V AC and 50 % load)
- DC to DC converter design
- High efficiency and reliability
- Fully modular cables
- 40 mm double ball bearing fan
- Seasonic S3FC (including Fanless mode)
- Short circuit protection on all outputs
- Over-voltage protection
- Over-power protection
- 100 % HiPot test
- 100 % Burn-in, high temperature cycled on/off
| DC Outputs | ||||||
|---|---|---|---|---|---|---|
| +3.3 V | +5 V | +12 V Combined | -12 V | +5 Vsb | Total continuous power | Input Type |
| 20 A | 20 A | 40 A | 0.3 A | 2.5 A | 500 W | Full range |
| 100 W (max.) | 480 W | 3.6 W | 12.5 W | |||
| Specifications | |
|---|---|
| Input frequency | 50 / 60 Hz |
| Efficiency (at normal input voltage) | > 87 % |
| Line regulation | ± 1 % (typical) |
| Load regulation | ± 5 % (typical) |
| Cross regulation | ± 5 % (typical) |
| MTBF, full load @ 25 °C ambient (excl. DC fan) | > 100,000 hours |
| Active Power Factor Correction | 99 % (typical) |
