Gigabyte B650M D3HP AX DDR5 AM5 Micro-ATX Motherboard

OVERVIEW

1. Solid Pin CPU Power Connector

2. 5+2+2 Digital VRM Design

3. HDMI, DisplayPort

4. DisplayPort

5. USB 3.2 Gen1 Type-C

6. USB 3.2 Gen1

7. 2.5 GbE LAN

8. 1*PCIe 4.0 x16 slot

9. PCIe 4.0 x 4 M.2 Connectors

10. PCIe 4.0 x 4 M.2 Connectors

11. Dual Channel SMD DDR5 Memory

12. Socket AM5 Supports AMD Ryzen™ Series Processors

13. Smart Fan 6
3*PWM/DC Fan Headers
Dual Fan Curve Mode

14. PCIe EZ-Latch

15. RGB FUSION
2*Addressable LED Header
1*RGB LED Header

16. Hi-Fi Audio
8-Ch HD Audio
Audio Noise Guard
High-End Audio Capacitor

17. 4*SATA 6Gb/s

18. 802.11 ax WI-FI

Durable Performance

GIGABYTE Ultra Durable™ motherboards built with optimal components inside out provide prime performance and a timeless platform.

Digital VRM Design - 5+2+2 Phases Digital VRM Solution with Low RDS(on) MOSFETs

GIGABYTE UD series motherboards use a 5+2+2 phases digital PWM + Low RDS(on) MOSFETs design to support AMD's new generation CPUs by offering incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components as well as delivering enhanced system performance and ultimate hardware scalability.

*Photo for reference only.

EXPO & XMP Support - DDR5 EXPO & XMP Overclocking Up to 7600 and Beyond*

GIGABYTE is offering a tested and proven platform that allows memory overclocking up to 7600 and beyond. To achieve this extreme memory performance boost, users need to ensure that their DDR5 memory modules are AMD EXPO™/ Intel® XMP capable and that the EXPO/XMP function is activated and enabled on their GIGABYTE motherboard.

* EXPO/XMP profile support may vary depending on memory modules.
* Please refer to the completed validated memory support list.
* Product features may vary by model.

EXPO & XMP Support - Unlock DDR5 Voltage

Secure Mode - MB provides fixed 5V to Native DDR5 memory and built-in PMIC outputs locked 1.1v to memory IC.

- GIGABYTE exclusive circuit design unlocks Native DDR5 voltage control
- Transforms Native DDR5 memory module to Overclocked DDR5 memory
- Increases DDR5 memory overclocking performance and capability
- Supports all PMIC vendors for maximum compatibility

* Memory overclocking capability will vary based on the user's hardware configuration

EXPO & XMP Support - GIGABYTE Exclusive DDR5 Circuit Design

Programmable Mode - GIGABYTE’s exclusive design unlocks Native DDR5 PMIC secure mode into programmable mode and controls Native DDR5 voltage with a wide range.

EXPO & XMP Support - Shielded Memory Routing

Note: The picture is for reference and may vary by mode.

All memory routing is under the PCB inner layer, which is shielded by a large ground layer to protect it from external interference.

EXPO and XMP Dual Support

GIGABYTE AM5 MB supports both AMD EXPO™ and Intel® XMP overclocking memory modules for maximal compatibility. MB will automatically detect both profiles format in SPD, users can choose to enable one of profiles from BIOS menu and easily reach overclocked memory performance.

EXPO & XMP Support - DDR5 Auto Booster

Automatically Boost the Native DDR5 frequency to 5000MHz while the system is under heavy loading by a single click.

AMD EXPO™ and Intel® XMP 3.0 User Profile

- SPD Re-defined or retrieve from the database.
- Performance Simulation
- Save/Load Profile
- Overclocked Performance
- Profile Clearance

Define and create your own SPD profile for Native, AMD EXPO™, and Intel® XMP 3.0 memory modules. One user-defined profile can be saved and loaded either locally or from/to an external storage device.

One empty SPD profile can be defined by users and carried to the next computer.
Quick memory performance simulation based on user input clock and timing parameters
Profile save and load function to share your memory parameters online.

Future Connectivity

The ultimate connectivity with blazing data-transfer speeds through the next-generation network and storage.

802.11ax Wi-Fi 6E

The latest Wireless solution, 802.11ax Wi-Fi 6E with a new dedicated 6GHz band, enables gigabit wireless performance, provides smooth video streaming, a better gaming experience, few dropped connections, and speeds up to 2.4Gbps. Moreover, Bluetooth 5 provides 4x the range over BT 4.2 and faster transmission.

2.5GbE LAN

Supercharge your gaming with 2.5GbE LAN. Achieve lightning-fast speeds, minimal lag, and unbeatable performance to elevate your gaming setup and dominate the competition.

PCIe 4.0 Hardware Design

GIGABYTE B650 Motherboards are ready to work with PCIe 4.0 devices, which are expected to experience twice the bandwidth of current PCIe 3.0 devices. To reach high speed and maintain good signal integrity, GIGABYTE R&D uses a low-impedance PCB to provide maximum performance.

* Photo for reference only.

Hi-Fi Audio

High-End Audio Capacitors - GIGABYTE motherboards use high-end audio capacitors. These capacitors help deliver high-resolution and high-fidelity audio, providing gamers with the most realistic sound effects.

Audio Noise Guard - GIGABYTE motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level.

Easy Friendly

Innovative and intuitive hardware, software, and BIOS interface design to create your personal style.

EZ-Latch

Unlock the PCIe slot latch easily when removing the graphics card in the PCIe slot.

Q-Flash Plus

Update the BIOS easily without installing the CPU, memory, and graphics card. With GIGABYTE Q-Flash Plus, you don't need to install the CPU, memory, and graphics card or enter the BIOS menu to flash the BIOS. Just download and save a new BIOS file (rename it to gigabyte.bin) on the USB flash drive, then press the dedicated Q-Flash Plus button, and you’re good to go!

STEP 1: Plug 24pin & 8pin power supply cable on motherboard
STEP 2: Download the motherboard BIOS file and rename it to "gigabyte.bin", save it to the USB flash drive, and plug the USB flash drive into the Q-Flash USB port
STEP 3: Press the Q-Flash Plus button, and the motherboard automatically updates the BIOS.

Smart Fan 6

Smart Fan 6 contains several unique cooling features that ensure a gaming PC maintains its performance while staying cool and quiet. Multiple fan headers can support a PWM/DC fan and pump, and users can easily define each fan curve based on different temperature sensors across the board via an intuitive user interface.

Cooling Features

- High Current Support: Each fan headers support PWM and DC fan and Water Cooling Pump, and up to 24W (12V x 2A) with Over-Current Protection

- Precision Control: Multiple temperature/fan speed control points for precise fan curve

- Dual Curve Mode: Slope/Stair dual mode for different user scenarios.

- Fan Stop: The fan can stop completely below the user's specified temperature point.

Smart Fan 6 BIOS UI

1. Improve fan curve UI: We increased the number of control points from 5 to 7 and added larger fan speed graphs for precise and easier fan curve control.

2. Slope/Stair dual graph mode: The fan curve can be quickly switched between Slope and Stair modes for different user scenarios. The slope is a traditional and intuitive linear fan speed curve. With the newly added Stair non-linear mode, the fan keeps at the same speed between specified temperature intervals.

3. Manual Input: We provide fan speed manual input for advanced users for more precise control.

4. EZ Tuning: The user can place 4 EZ Tuning points at rough temperature/fan speed, and Smart Fan 6 can quickly generate a fan curve.

5. Fan curve profile: The fan curve profile can be saved in the BIOS ROM and kept after updating the BIOS.

Note: The picture is for reference and may vary by model.

GIGABYTE Control Center

GIGABYTE CONTROL CENTER (GCC) is unified software for all GIGABYTE-supported products. It provides a newly designed intuitive user interface for controlling all essential functions.

- Unified software platform for all Gigabyte supported products
- Intuitive user interface for an eased experience
- Modularised control components only for installed hardware
- Auto update function to keep the system up to date and support future products
