Audioengine D1P DAC/Headphone amp (Grey)
Description
• Audioengine D1P 32 Bit Portable Headphone Amplifier & DAC Input bit depth: Up to 32 bits
• Input sample rate (USB): PCM Max. 32bit 384KHz, Max 24bit 192KHz
• DSD Support: DSD 64, 128 (DOP), DSD 256 (Native)
• MQA Rerender: 8X
• USB device class: UAC 2.0
• Inputs: USB Type-C, S/PDIF Optical (Max 24bit 192KHz), Toggle Switch for input selection
• Outputs: Standard 3.5mm headphone port, RCA, SPDIF
• Frequency Response: 20Hz-40KHz +/-0.1dB
• D1P
• Input sample rate (USB): PCM Max. 32bit 384KHz, Max 24bit 192KHz
• DSD Support: DSD 64, 128 (DOP), DSD 256 (Native)
• MQA Rerender: 8X
• USB device class: UAC 2.0
• Inputs: USB Type-C, S/PDIF Optical (Max 24bit 192KHz), Toggle Switch for input selection
• Outputs: Standard 3.5mm headphone port, RCA, SPDIF
• Frequency Response: 20Hz-40KHz +/-0.1dB
• D1P
$249.00
Sale price
$249.00
In stock at Mwave
Dispatch or pick up within 24 hours
BANK TRANSFER (EFT)
$249.00
Sale price
$249.00
In stock at Mwave
Dispatch or pick up within 24 hours
Accepted payment methods
Description
• Audioengine D1P 32 Bit Portable Headphone Amplifier & DAC Input bit depth: Up to 32 bits
• Input sample rate (USB): PCM Max. 32bit 384KHz, Max 24bit 192KHz
• DSD Support: DSD 64, 128 (DOP), DSD 256 (Native)
• MQA Rerender: 8X
• USB device class: UAC 2.0
• Inputs: USB Type-C, S/PDIF Optical (Max 24bit 192KHz), Toggle Switch for input selection
• Outputs: Standard 3.5mm headphone port, RCA, SPDIF
• Frequency Response: 20Hz-40KHz +/-0.1dB
• D1P
View Full Details
• Input sample rate (USB): PCM Max. 32bit 384KHz, Max 24bit 192KHz
• DSD Support: DSD 64, 128 (DOP), DSD 256 (Native)
• MQA Rerender: 8X
• USB device class: UAC 2.0
• Inputs: USB Type-C, S/PDIF Optical (Max 24bit 192KHz), Toggle Switch for input selection
• Outputs: Standard 3.5mm headphone port, RCA, SPDIF
• Frequency Response: 20Hz-40KHz +/-0.1dB
• D1P
Hear What You've Been Missing
For those demanding the best sound quality, the D1P enhances music streaming to high-fidelity, exceeding the capabilities of traditional audio equipment.
It bypasses the limitations of standard device sound cards, ensuring that your favorite tracks from platforms like Tidal, Apple Music, or Spotify are delivered in studio-level quality. Supporting high-resolution audio formats — including PCM up to 32bit 384KHz, DSD up to 256, and MQA files — the D1P allows you to immerse yourself in the full depth of your music, unveiling every note with clarity and detail.
Power Meets Efficiency
The D1P showcases an exceptional ability to deliver ample power to drive audiophile-grade headphones between 10 to 600 ohms without draining unnecessary power from your device. This precision in power management ensures your listening sessions are extended, with uncompromised sound quality.
Versatility in the Palm of Your Hand
USB C Input: Provides a modern, high-quality connection to your devices for both power and audio.
Optical Input: Ensures compatibility with home theaters, TV's and devices with optical outputs.
Analog Output: Offers connections to any speaker setup, from vintage amps to modern systems.
Headphone Jack: Supports a broad spectrum of headphones for personalized listening.
Tailored Listening
Audioengine values your control over the listening experience. The D1P features an output toggle switch, allowing you to smoothly switch between headphones or speakers. This control lets you fill the room with music or immerse yourself in a private listening session, catering to your preference at on demand.
From Desk to Destination: Premium Sound That Follows You
Are you tired of being tethered to your desk or home for high-quality music experiences? The D1P breaks down these barriers, enhancing your listening experience wherever you go. With the D1P, high-fidelity sound isn't confined to a single location; it follows you.
Whether you're perfecting a playlist at your desk or savoring a moment of relaxation in a café, the D1P ensures your music always meets the highest standard of clarity and depth. This compact powerhouse transforms any space into your personal concert hall, proving that premium sound quality can travel with you, everywhere. Embrace the freedom to enjoy your favorite tracks without compromise, no matter where life takes you.
SPECIFICATIONS
DAC Chip:
SA9312+ES9219C
Input bit depth:
Up to 32 bits
Input sample rate (USB):
PCM Max. 32bit 384KHz, Max 24bit 192KHz
DSD Support:
DSD 64, 128 (DOP), DSD 256 (Native)
MQA Rerender:
8X
USB device class:
UAC 2.0
Inputs:
USB Type-C
S/PDIF Optical (Max 24bit 192KHz)
Toggle Switch for input selection
Outputs:
Standard 3.5mm headphone port for headphones and headsets
RCA
SPDIF
Full-scale output level:
Max. 2.05Vrms @ 10K default
Output impedance:
<0.5R @ Headphone, 47R @ RCA
Recommended headphone impedance range:
10 Ohms ~ 600 Ohms
Frequency Response:
20Hz-40KHz +/-0.1dB
Signal-to-Noise Ratio (SNR):
121dB (10K)
Power Requirement:
USB 5V DC
Consumption:
~102mA (normal), ~121mA (with pink noise at 50% volume, 32bit 384Khz)
Indicators:
White: power/connected
Green: PCM 88.2-192kHz / DSD64
Blue: PCM 352.8-384kHz / DSD128
Purple: MQA
Green: Optical
Product dimensions
3.0" (7.62 cm) x 2.5" (6.35 cm) x 1" (2.5 cm)
Shipping weight
13.7 oz (0.39kg)
Environmental
Operating Temperature: 32 to 95 degrees F
Non-operating Temp: -4 to 113 degrees F
Relative Humidity: 5% to 95% non-condensing
Included Accessories:
USB-C cable
Lighning Cable
Setup guide
Microfiber bag
Audioengine D1P 32 Bit Portable Headphone Amplifier & DAC
D1P
DSD Support: DSD 64
128 (DOP)
DSD 256 (Native)
Frequency Response: 20Hz-40KHz +/-0.1dB
Input bit depth: Up to 32 bits
Input sample rate (USB): PCM Max. 32bit 384KHz
Max 24bit 192KHz
Inputs: USB Type-C
S/PDIF Optical (Max 24bit 192KHz)
Toggle Switch for input selection
MQA Rerender: 8X
Outputs: Standard 3.5mm headphone port
RCA
SPDIF
USB device class: UAC 2.0
D1P
DSD Support: DSD 64
128 (DOP)
DSD 256 (Native)
Frequency Response: 20Hz-40KHz +/-0.1dB
Input bit depth: Up to 32 bits
Input sample rate (USB): PCM Max. 32bit 384KHz
Max 24bit 192KHz
Inputs: USB Type-C
S/PDIF Optical (Max 24bit 192KHz)
Toggle Switch for input selection
MQA Rerender: 8X
Outputs: Standard 3.5mm headphone port
RCA
SPDIF
USB device class: UAC 2.0
